The IoT/M2M Cookbook

A complete guide to wireless antenna design €90 plus V.A.T.

Networks evolve, radio design remains key

Twenty-five years ago, there was no “M2M” or “IoT”. Developers used Frequency Shift Keying (FSK) on Private Mobile Radios (PMR) with communication speeds of up to 3600 bits per second. Then came public analogue trunked radios followed by GSM with its Short Message Service (SMS) and Circuit Switched Data (CSD) at 9600 bits per second and global roaming offering worldwide data communication followed by 2.5 and 3G with higher data speeds.

Today, GSM/GPRS is being gradually phased out and is being replaced by 4G and 5G technology. GSM networks have been switched off in the USA, Australia, Singapore and many other countries. Devices for pan-European use must therefore support 2G, 3G and 4G, whereas in the USA, NB-IoT or LTE-M is sufficient.

NB-IoT and LTE-M are the new stars in the IoT and M2M firmament and combine classic cellular radio networks with LPWAN. The base station antennas for LTE are also used for NB-IoT and LTE-M. Both techniques have new variable timers, which allow the management of wireless activity and extends the potential operational life of devices to many years without the need for a service visit.

There are different terms used for these new classes of devices and the ways that they communicate, M2M, IoT, IIoT Industry 4.0 and so on. Applications for all of these often use the same wireless technology. The names are not important here because building cost-effective and efficient wireless radios is a common requirement.

The IoT/M2M Cookbook

The goal of the book is to guide developers from the concept stage of an IoT/M2M device all the way to the final mass-produced product. In many cases, it provides developers with information often omitted in the technical documentation provided by radio module and antenna manufacturers.

The IoT/M2M Cookbook describes in detail how to develop a tracking device based on cellular and Global Navigation Satellite System (GNSS) modules. The navigation system for trucks described in the book uses six different wireless technologies (2G, 3G, GNSS, Classic Bluetooth, Bluetooth Low Energy and NFC) with five different antennas within one enclosure.

The book also covers an inverted F PCB antenna for GSM, NB-IoT and LTE-M and how to redesign it using the ground plain of your PCB and how to encapsulate the whole design in epoxy resin. It also explains how to integrate a chip or PCB antenna with coaxial cable. Some power supply concepts including LT Spice modules for DC/DC regulators and load generator for the 2 Ampere peak currents are included in the book, too.

Common pitfalls are explained, for example the fact that the power down reset is a common fault in designs with cellular modules.

If you would like to see the full contents and some samples, please click here.

If you’re ready to go ahead, simply hit the “buy now” button or click here and we’ll immediately send you the instructions on how to buy the book

We offer a range of services to help you succeed, read more about these and a real customer example here.

The LPWAN Cookbook

Coming soon. A complete guide to building successful LPWAN designs.  Register your interest here and we will contact you when it is published.

Example: how to design a dual F antenna

The IoT M2M Cookbook contains a simulation of a dual F antenna for a range of wireless networks.

The two antenna arms work independently of each other and as a result allow the combination of NB-IoT/LTE-M (SubGHz) with BLE/WiFi or the combination of NB-IoT/LTE-M with GNSS. These combinations are used in low-cost trackers, cellular/BLE gateways or in waterproof sensors.

This antenna design has been customized several times by customers, or by the akorIoT team on behalf of customers.
